A Fresh Way To Showcase Canvas Prints: DIY Floating Frames

artworks on a white wall with floating frames

DIY expert, Amaryllis of Oh Oh Blog shows us a fresh (and seriously simple) new way to hang your canvas prints

Framing your wall art is a great way to give more elegance to any art piece. Unfortunately frames can be really expensive. If you own a canvas and want to enhance it, building a floating frame for it is an easy and budget friendly project to realize. It will give your art piece an all new visual impact.

diy floating frame materials

Material you will need to build a floating frame:

  • Wood pieces of 3/4“ thick
  • 4 metallic brackets of 2 ½ “
  • 4 metallic mending plates of 3” long
  • Screws
  • A drill with a 1/16 bit
  • A screw driver
  • Sanding paper and a sander machine (optional)
artwork in floating frames
angled view artwork in floating framesartwork hung over bookshelf

marking frame with pencil

Step 1

We used ¾” thick wood but you can choose any thickness you want. Cut the wood pieces at the accurate dimension. The two vertical pieces, must be the same dimension as the high of your canvas more the two bracket edges thickness.

Example: Our canvas is 18” high and the brackets are 1/8” thick, so 1/8” + 1/8” + 18”= 18 ¼ “ is the length of our two vertical wood pieces.

The two horizontal pieces must be the same dimensions as the width of the canvas, more two wood thickness, more two bracket's thickness.

Example: Our canvas is 13” width, the wooden pieces we use are ¾” thick and the brackets are ⅛” thick, so 13” + ¾” +¾” +⅛” +⅛” = 14 ¾” is the length of our two horizontal wood pieces.

Once the pieces are cut, check that they fit perfectly around your canvas. Place a bracket at the base of each corner and mark the screws position.

drilling holes on frame marks

Step 2

Following your marks, drill small holes at each screw location.

screw bracket on frame

Step 3

Screw a bracket in each corner of your frame. Check that the wood pieces are perpendicular to one another.

sanding frame

Step 4

Sand you frame. You can use a sander or doing it by hand if you don’t own one. Take off the dust with a wet cloth and apply a coat of transparent varnish. You can also choose to stain or paint the wood if you like too.

placing canvas on frame

Step 5

Place your canvas into the frame. Screw a mending plate in every corner to fix the frame and the canvas together. The canvas already has a wire to hang, so just put a nail on the wall, hang your art and enjoy it!

artworks in diy floating frames
